The Rexnord Link-Belt F3Y227NC1Z42 is a 1-11/16 inch mounted ball bearing designed for standard-duty applications. This bearing features a cast iron 4-bolt square flange block housing, providing robust support and stability.
Key Features
- Bore Size: 1.6875 inches (1-11/16″)
- Housing Material: Durable cast iron with a powder-coated finish for enhanced corrosion resistance
- Locking Mechanism: Eccentric cam locking collar ensures a secure fit on the shaft
- Seal Type: Single lip contact seal to protect against contaminants
- Lubrication: Pre-filled with 100% grease and equipped with a 1/8 NPT grease fitting for easy maintenance
- Housing Design: Machined for steel end closure, with the housing plugged for added protection
Specifications
- Dynamic Load Capacity: 7,370 lbs
- Static Load Capacity: 4,590 lbs
- Maximum Speed: 5,330 RPM
- Operating Temperature Range: Up to 225°F (107°C)
- Mounting Bolt Size: 1/2 inch
- Distance Between Bolt Holes: 4 1/8 inches
- Distance from Mounting Surface to Cap Face: 2 9/32 inches
This bearing unit is engineered for reliability and ease of installation, making it suitable for various industrial applications requiring dependable performance.
