Protec Process Technology Temperature Control D15D

The **Protec Process Technology Temperature Control D15D** is a digital thermostat engineered for precise temperature regulation in industrial applications such as plating, etching, and chemical processing.

Key Features

• Temperature Range: Adjustable from -40°F (-40°C) to 999°F (538°C), accommodating a wide array of process requirements.
• Display: Equipped with a large, easy-to-read LED display (.56” high) for clear visibility of temperature readings.
• Sensor: Includes a 10-foot (3m) fluoropolymer (FEP) covered, 1000-ohm platinum RTD sensor, ensuring accurate and reliable temperature measurements.
• Enclosure: Housed in a vapor-resistant, NEMA 1, IP21, gasketed plastic enclosure with stainless steel hardware, providing durability in harsh environments.
• Switching Capacity: Features a single pole, double throw switch rated at 15 amps for either 120 or 240 volts, suitable for single-phase operations.
• Accuracy: Offers ±0.25% full span, single-digit accuracy, ensuring precise temperature control.
• Alarm Functionality: Programmable high alarm shutdown enhances safety by alerting users to over-temperature conditions.
• Protection Features: Incorporates sensor short and break protection to maintain system integrity.

Applications

The D15D is ideal for industries requiring consistent and accurate temperature control, including:

• Plating tanks
• Etching processes
• Chemical processing
• Industrial heating and cooling systems

Specifications

• Voltage: 100-240V ±10%
• Maximum Amperage: 15 amps (Note: 12 amp full load max if operating a heater with a built-in thermal protector)
• Ambient Temperature Range: 20°F (-7°C) to 130°F (54°C)
• Certifications: cULus and CE compliant

The Protec Process Technology Temperature Control D15D combines precision, durability, and user-friendly features, making it a reliable choice for demanding industrial temperature control applications.
