Motorola 6-5576 4700-10-1 Carbon Composition Axial Resistor Vintage 4.7kΩ 2W 5%

Motorola 6-5576 4700-10-1 Carbon Composition Axial Resistor

The Motorola 6-5576 4700-10-1 is a vintage carbon composition axial resistor, offering a resistance of 4.7kΩ with a power rating of 2 watts and a tolerance of ±5%. This component is designed for through-hole mounting, making it suitable for various electronic applications.

Key Features

• Resistance: 4.7kΩ
• Power Rating: 2W
• Tolerance: ±5%
• Composition: Carbon Composition
• Mounting Type: Through-Hole

Applications

Carbon composition resistors like the Motorola 6-5576 4700-10-1 are commonly used in applications requiring high energy dissipation and pulse handling capabilities. They are ideal for vintage electronic equipment restoration, audio circuits, and other projects where traditional resistor characteristics are desired.

Dimensions

While specific dimensions for this model are not readily available, carbon composition resistors typically feature a cylindrical body with axial leads, facilitating easy integration into circuit designs.

Note

As a vintage component, the Motorola 6-5576 4700-10-1 may be sought after by enthusiasts and professionals working on restoration projects or designs that benefit from the unique properties of carbon composition resistors.
