The Martin 120623 QD Quick Disconnect Bushing J-3-3/8 is a high-quality component designed for efficient and secure mounting of various mechanical parts.
Key Features
- Size and Compatibility: This bushing is classified as a Size J, featuring a 3-3/8 inch bore diameter, making it suitable for a wide range of applications.
- Material Construction: Constructed from durable cast iron, it ensures longevity and reliable performance under demanding conditions.
- Design Specifications: The bushing includes a 7-1/4 inch flange diameter and a 9 inch hub diameter, providing a robust and stable connection.
- Installation Ease: Equipped with a 4-degree angled taper and a flanged design, it facilitates easy installation and removal, enhancing operational efficiency.
- Standardization: Manufactured to meet or exceed industry standards, ensuring compatibility and interchangeability with other QD bushings.
Technical Specifications
- Bore Diameter: 3-3/8 inches
- Barrel Diameter: 5.14 inches
- Flange Diameter: 7-1/4 inches
- Hub Diameter: 9 inches
- Flange Thickness: 1 inch
- Overall Length: 4-1/2 inches
- Keyway Size: 7/8 x 7/16 inches
- Number of Bolt Holes: 3
- Screw Size: 5/8-11 x 4-1/2 inches
- Torque Rating: 45,000 in-lb
The Martin 120623 QD Bushing is engineered for versatility and durability, making it an ideal choice for various industrial applications requiring quick and secure component mounting.
