Lite-On LPTL12357AABW2 5×7 Dot Matrix LED Display Module The Lite-On LPTL12357AABW2 is a high-performance 5×7 dot matrix LED display module designed for clear and efficient visual representation in various applications. This module features a common cathode row and common anode column configuration, facilitating straightforward integration into electronic systems. Key Features Display Configuration: 5×7 dot matrix, suitable for alphanumeric and simple graphic displays. Color Options: Dual-color capability with Green and Orange-Red LEDs, offering versatile display possibilities. Forward Voltage: Typical forward voltages are 2.1V for Green and 2.0V for Orange-Red LEDs, ensuring energy-efficient operation. Luminous Intensity: Each LED provides a luminous intensity of 2 millicandelas (mcd), delivering clear and visible output. Compact Dimensions: The module measures 0.50″ (12.66mm) in length, 0.70″ (17.74mm) in width, and 0.25″ (6.30mm) in height, making it suitable for space-constrained applications. Internal Connection: Designed with a common cathode row and common anode column configuration, simplifying the driving circuitry. Applications The LPTL12357AABW2 is ideal for integration into: Industrial control systems Instrumentation panels Point-of-sale equipment Consumer electronics Automotive displays Its dual-color display and compact size make it a versatile choice for applications requiring clear and reliable visual feedback. Technical Specifications Display Type: Dot Matrix Matrix Configuration: 5×7 LED Colors: Green and Orange-Red Forward Voltage (Typical): 2.1V (Green), 2.0V (Orange-Red) Luminous Intensity: 2mcd per LED Dimensions: 0.50″ L × 0.70″ W × 0.25″ H (12.66mm × 17.74mm × 6.30mm) Internal Connection: Common Cathode Row, Common Anode Column The Lite-On LPTL12357AABW2 5×7 Dot Matrix LED Display Module combines efficient performance with a compact design, making it a suitable component for a wide range of electronic display applications.
