IFM Efector100 30137 IFB3004BBPKG/M/US-104-DPS Inductive Sensor IFS204

IFM Efector100 30137 IFB3004BBPKG/M/US-104-DPS Inductive Sensor IFS204

The IFM Efector100 IFS204 is a high-performance inductive sensor designed for precise metal object detection in industrial automation applications. Its compact and robust design ensures reliable operation even in challenging environments.

Key Features

• Compact Design: The sensor features a short housing, making it ideal for installations where space is limited.
• Durable Construction: Built with a robust metal housing, it is suitable for harsh industrial conditions.
• Enhanced Sensing Range: Offers an increased sensing range of 4 mm, reducing the risk of physical damage and ensuring high uptime.
• High Switching Frequency: Capable of operating at a switching frequency of up to 700 Hz, allowing for rapid response times.
• Clear Status Indication: Equipped with four yellow LEDs for easy and clear indication of the switching status.

Technical Specifications

• Electrical Design: PNP
• Output Function: Normally open
• Operating Voltage: 10 to 30 V DC
• Current Consumption: Less than 10 mA
• Protection Class: II
• Reverse Polarity Protection: Yes
• Short-Circuit and Overload Protection: Yes
• Sensing Range: 4 mm
• Real Sensing Range (Sr): 4 ± 10%
• Operating Distance: 0 to 3.25 mm
• Ambient Temperature Range: -25 to 70°C
• Enclosure Rating: IP67
• Housing Material: Brass with white bronze coating; sensing face made of orange PBT
• Connection Type: M12 connector with gold-plated contacts
• Dimensions: M12 x 1 thread, 45 mm length
• Mounting: Flush mountable

The IFM Efector100 IFS204 inductive sensor combines advanced features with durable construction, making it a reliable choice for various industrial automation applications.
