Hubbell Fluorescent Emergency Ballast E-100

The Hubbell Fluorescent Emergency Ballast E-100 is a reliable solution for converting standard fluorescent fixtures into emergency lighting sources. Designed to ensure safety and compliance, this ballast provides consistent illumination during power outages.

Key Features

• Illumination Time: Operates one lamp in emergency mode for a minimum of 90 minutes, ensuring adequate egress lighting during emergencies.
• Initial Lumen Output: Delivers an initial output of 500 lumens, providing sufficient brightness for safety and visibility.
• Dual Voltage Capability: Supports both 120V and 277V inputs at 60Hz, offering flexibility for various installation requirements.
• Battery: Equipped with a long-life, maintenance-free, rechargeable sealed nickel-cadmium (NiCd) battery, ensuring dependable performance over time.
• Construction: Housed in durable painted steel with a white finish, the compact design fits most fluorescent fixtures and is suitable for installation inside, on top, or remote from the fixture.
• Compliance: Meets UL924, NFPA 101 Life Safety Code, NEC, OSHA, and other local and state codes. UL listed for damp locations, ensuring adherence to safety standards.

Specifications

• Dimensions: 9.5″ x 2.4″ x 1.5″
• Weight: Approximately 2.1 lbs
• Operating Temperature: Suitable for ambient temperatures ranging from 0°C to 50°C (32°F to 122°F)
• Recharge Time: Fully recharges the battery within 24 hours
• Warranty: Comes with a five-year warranty against defects in material and workmanship

Compatibility

The E-100 is compatible with most one, two, three, and four-lamp electronic standard and dimming AC ballasts. It operates one 17W-40W, one 17W-110W T8 through T12, one 13W-26W 4-pin compact, and 18W-36W 4-pin long compact fluorescent lamps.

Ensure your facility’s safety and compliance with the Hubbell Fluorescent Emergency Ballast E-100, a dependable choice for emergency lighting solutions.
