Gates 2/5VX600 Super HC PowerBand V-Belt

The Gates 2/5VX600 Super HC PowerBand V-Belt is engineered for high-performance industrial applications, offering enhanced power transmission capabilities in a compact design. This belt is ideal for heavy-duty drives where space, weight, and horsepower capacity are critical considerations.

Key Features

• Flex-Bonded Tensile Cords: Vulcanized as a single unit, these cords provide exceptional resistance to tensile and flexing forces, fatigue, and shock loads, ensuring uniform load distribution and prolonged belt life.
• Precision-Ground Straight Sidewalls: Designed to deliver uniform wedging action, these sidewalls ensure the belt fits correctly in pulley grooves, enhancing belt longevity and reducing maintenance requirements.
• Patented Ethylene Elastomeric Compound: This advanced material, combined with optimized molded notches, increases flexibility and transmission efficiency, allowing for more compact and economical drive designs by reducing the size of pulleys, bearings, guards, and mounts.
• PowerBand Construction: Multiple belts are joined together by a permanent, high-strength tie band, providing high lateral rigidity and preventing belt whip, turnover, or jumping off the drive, especially in applications exposed to pulsating or heavy shock loads.
• Temperature Resilience: Operates effectively within a wide temperature range of -60°F to +250°F (-51°C to +121°C), maintaining performance in diverse environmental conditions.
• Compliance and Standards: Meets ARPM/RMA IP-3-2 oil and heat resistance standards and IP-3-3 static conductivity requirements. Additionally, it is REACH and RoHS 2 compliant, ensuring adherence to environmental and safety regulations.

Specifications

• Section: 5VX
• Number of Strands: 2
• Nominal Outside Length: 60 inches
• Top Width per Strand: 5/8 inch
• Total Top Width: 1-1/4 inches
• Overall Height: 0.5469 inches
• Effective Length: 59.88 inches (1521 mm)
• Material: Ethylene Elastomeric
• Reinforcing Cord Material: Polyester
• Operating Temperature Range: -60°F to +250°F (-51°C to +121°C)
• Resistance Features: Oil Resistant
• Color: Black
• Country of Origin: USA

The Gates 2/5VX600 Super HC PowerBand V-Belt is a reliable solution for demanding industrial applications, offering superior performance, durability, and efficiency in power transmission systems.
