EMX Industries Loop Detector D-TEK-24V DC

EMX Industries D-TEK-24V DC Loop Detector

The EMX Industries D-TEK-24V DC Loop Detector is a reliable and efficient solution for vehicle detection in access control systems. Designed to operate seamlessly with 24V DC power supplies, this detector ensures accurate vehicle presence monitoring for gates, barriers, and other automated systems.

Key Features

• Power Supply: Operates on 24V DC, making it compatible with standard DC power systems.
• Fail Safe and Fail Secure Modes: Offers flexibility to operate in both fail safe and fail secure configurations, enhancing safety and security.
• Sensitivity Settings: Equipped with 10 adjustable sensitivity levels, allowing precise detection tailored to specific application requirements.
• Surge Protection: Enhanced lightning and surge immunity safeguards the detector against electrical disturbances.
• Loop Diagnostics: Built-in diagnostics facilitate easy troubleshooting and maintenance.
• Loop Isolation Transformer: Ensures reliable operation even with marginal loops by providing transformer isolation.
• Aluminum RF Shield Housing: The robust aluminum housing offers durability and protection against radio frequency interference.
• Dual Relay Outputs: Features two relays configurable for presence and pulse or dual presence detection, enhancing versatility.

Technical Specifications

• Power Supply: 24V DC
• Current Consumption: 9.5 mA at 24V DC
• Operating Temperature: -40°F to +180°F
• Loop Inductance Range: 20 – 2000 µH with a Q-factor of 5 or higher
• Housing Dimensions: Height: 3.25” (83mm), Width: 2.56” (40mm), Length: 3.65” (90mm)
• Connector: 86CP11 11-pin male

The D-TEK-24V DC Loop Detector is engineered for easy installation and reliable performance, making it an ideal choice for various vehicle detection applications in access control systems.
