Dwyer 0-1In 15PSIG Magnehelic Gauge 2001

Dwyer 2001 Magnehelic® Differential Pressure Gauge

The Dwyer 2001 Magnehelic® Differential Pressure Gauge is a precision instrument designed to measure low air or non-combustible gas pressures. It offers accurate readings for positive, negative, or differential pressures, making it ideal for various applications.

Key Features

• Measurement Range: 0 to 1.0 inches of water column (w.c.) with minor divisions of 0.02 inches.
• Accuracy: ±2% of full scale at 70°F (21.1°C).
• Pressure Limits: -20 inches Hg to 15 psig.
• Temperature Range: Operates between 20°F to 140°F (-6.67°C to 60°C).
• Construction: Die-cast aluminum case with an acrylic cover, ensuring durability and resistance to shock, vibration, and overpressure.
• Mounting Options: Equipped with both back and side connections, allowing for versatile surface or flush mounting.
• Process Connections: 1/8″ female NPT duplicate high and low-pressure taps.
• Enclosure Rating: IP67, providing protection against dust and water ingress.

Applications

The Dwyer 2001 Magnehelic® Gauge is commonly used in HVAC systems, clean rooms, and industrial processes to monitor fan and blower pressures, filter resistance, air velocity, and more. Its reliable performance and easy-to-read 4-inch dial make it a preferred choice for professionals seeking accurate pressure measurements.
