The Dodge Baldor HE40 X 3-15/16 KW Hub Taper Bushing (Part Number 206656) is a robust and reliable component engineered for secure mounting of conveyor pulleys. Its design ensures optimal performance in demanding industrial applications.
Key Features
- Dependable Mounting System: Specifically crafted for drum and wing pulleys, providing a secure and stable connection.
- Flange Mount Design: Facilitates straightforward installation and removal, enhancing operational efficiency.
- Optimized Taper Angle: The 14-degree taper angle minimizes axial movement along the shaft, ensuring a tight and secure fit.
- Reduced Disc Deflection: Engineered to decrease disc deflection and prestressing, thereby extending the lifespan of connected components.
Specifications
- Bore Diameter: 3-15/16 inches
- Hub Diameter: 2-1/2 inches
- Bolt Circle Diameter: 6-5/16 inches
- Flange Diameter: 7-1/2 inches
- Flange Thickness: 1 inch
- Number of Bolt Holes: 4
- Radial Load Capacity: 140 ft-lb
- Overall Length: 3-1/2 inches
- Keyway Size: 1 x 1/4 inch
This bushing is an integral part of conveyor systems, ensuring the secure attachment of pulleys to shafts, thereby enhancing the efficiency and reliability of material handling operations.
