Diodes Inc. MBRB1S40CT-T SMD Components on Tape & Reel
The MBRB1S40CT-T from Diodes Incorporated is a Schottky Barrier Rectifier designed for surface-mount applications. Packaged in a D²PAK (TO-263AB) configuration, this component is optimized for high-efficiency performance in power management systems.
Key Features
- Low Forward Voltage Drop: Enhances efficiency by reducing power loss during conduction.
- High Surge Capability: Capable of withstanding high surge currents, ensuring reliability in transient conditions.
- Guard Ring Die Construction: Provides enhanced protection against transient voltage spikes.
- High Current Capability: Supports applications requiring substantial current flow.
Electrical Specifications
- Maximum Repetitive Reverse Voltage (VRRM): 40V
- Maximum Average Rectified Current (IO): 15A per diode
- Forward Voltage Drop (VF): 0.7V at 7.5A
- Peak Forward Surge Current (IFSM): 150A
- Maximum Reverse Current (IR): 100µA at 40V
Mechanical Specifications
- Package Type: TO-263AB (D²PAK)
- Mounting Type: Surface Mount
- Weight: Approximately 1.7 grams
Applications
- Switching Power Supplies
- DC-DC Converters
- Free-Wheeling Diodes
- Reverse Battery Protection
The MBRB1S40CT-T is supplied on tape and reel, facilitating automated assembly processes and ensuring consistent quality in high-volume manufacturing environments.
