Digital Techniques Division Gage Model 730-005

The Digital Techniques Division Gage Model 730-005 is a precision instrument designed for accurate measurement applications in various industrial settings.

Key Features

• Measurement Range: Capable of measuring thicknesses from 0.020 to 20 inches (0.50 mm to 508 mm) in steel, depending on material, temperature, and transducer selection.
• Material Velocity Calibration Range: Adjustable from 0.0200 to 0.7362 inches per microsecond (0.508 to 18.699 mm/µs).
• Operating Temperature: Functions effectively between -4°F to 122°F (-20°C to 50°C). High-temperature transducers are available for material temperatures ranging from -5°F to 950°F (-20.5°C to 510°C).
• Battery Life: Offers up to 50 hours of continuous operation, or 20 hours with the backlight activated.
• Display: Features a 128 x 64 graphics LCD monochrome screen that is sunlight-readable.
• Language Support: Supports multiple languages, including English, French, Spanish, Italian, Czech, German, Portuguese, Slovak, Finnish, Hungarian, and Chinese.
• Resolution: User-selectable resolutions of 0.001 inches (0.01 mm) or 0.01 inches (0.1 mm).
• Probe Recognition: Utilizes a menu-based pick list for easy probe selection.
• Delay Line Auto Zero Measurement: Automatically calibrates at power-up, correcting for delay line wear and transducer acoustic drift at elevated temperatures.
• Construction: Housed in an IP54-rated, splash-proof, high-impact plastic casing with an illuminating rubber keypad for go/no-go testing.
• Bandwidth: Operates within a 0.5-20 MHz (-3dB) bandwidth.
• Units: Selectable between English, Metric, and Microseconds.
• Gain Settings: Offers Low, Standard, and High gain settings for varying test conditions, with 1 dB steps from 20-90 dB or Automatic Gain Control (AGC) for models with a waveform.
• Fast Min/Max Mode: Simultaneously displays minimum or maximum and actual thickness values at 20 measurements per second.
• Differential Mode: Displays the difference from the actual thickness measurement in absolute or percentage of a user-entered reference value.
• Alarms: Configurable minimum and maximum depth alarms with visual, audible, and tactile feedback, including keypad illumination.
• Illuminating Keypad: Color-coded function keys (F1 = Red, F2 = Yellow, F3 = Green) for easy go/no-go testing.

Applications

The Model 730-005 is ideal for industries requiring precise thickness measurements, such as manufacturing, quality control, and material testing. Its robust design and versatile features make it suitable for both laboratory and field environments.

Specifications

• Size: 5″ (127 mm) L x 3″ (76.2 mm) W x 1.25″ (31.75 mm) H
• Weight: 8 oz (0.23 kg)
• Battery Type: 2 “AA” Alkaline

The Digital Techniques Division Gage Model 730-005 combines advanced measurement capabilities with user-friendly features, ensuring reliable performance across a wide range of applications.
