Deltrol Controls 05A 20118-8 General Purpose Relay

The Deltrol Controls 05A 20118-8 General Purpose Relay is a versatile and reliable component designed to manage electrical loads up to 10 Amps. This relay is part of Deltrol’s 105 Series, known for its durability and adaptability across various applications.

Key Features

• High Load Capacity: Capable of handling electrical loads up to 10 Amps, making it suitable for a wide range of industrial and commercial uses.
• Multiple Pole Configurations: Offers configurations up to 3PDT (Triple Pole Double Throw), providing flexibility for complex circuit designs.
• Durable Coil Insulation: Equipped with a Class F coil insulation system rated for total temperatures up to 155°C, ensuring reliable performance under demanding conditions.
• Environmental Protection: The coil is molded in polyester, offering enhanced protection against environmental factors and extending the relay’s lifespan.
• Stable Operation: Features a unique armature stop that maintains precise adjustment, contributing to consistent and dependable operation.

Typical Applications

The 05A 20118-8 relay is commonly utilized in various applications, including:

• Lighting controls
• Time delay controls
• Industrial machine controls
• Energy management systems
• Control panels
• Forklifts
• HVAC systems

Mounting and Termination Options

This relay offers versatile mounting options, including panel, bracket, socket, and PC terminal configurations, allowing for seamless integration into various systems. The standard 8 or 11-pin socket termination facilitates easy installation and replacement.

Additional Models

The 105 Series includes several models to cater to specific requirements:

• 105: Standard 8 or 11-pin socket termination.
• 105A: Includes an indicator lamp to signal voltage to the coil.
• 105G: Features a standard cover with a Neoprene gasket for enhanced protection.
• 105T: A sensitive coil version utilizing 125 MW per pole.

The Deltrol Controls 05A 20118-8 General Purpose Relay combines robust construction with flexible features, making it an ideal choice for managing electrical loads in diverse applications.
