The Brad Connectivity 6-Pole Male Straight Receptacle with 12-inch 16 AWG PVC Leads, part number 1R6006A20A120, is a robust and reliable connector designed for industrial applications requiring secure and efficient electrical connections.
Key Features
- Connector Type: 6-pole male straight receptacle
- Wire Gauge: 16 AWG
- Lead Length: 12 inches (0.305 meters)
- Voltage Rating: 600 VAC/VDC
- Current Rating: 8 A per contact
- Body Material: Die-cast zinc with black epoxy coating
- Mounting Thread Size: 1/2″-14 NPT
- Coupling Thread Size: 7/8″-16
- IP Rating: IP67, providing protection against dust and temporary submersion
- NEMA Rating: NEMA 6P
- Operating Temperature Range: -4°F to 221°F (-20°C to +105°C)
- Standards Compliance: UL Listed (E152210), CSA Certified (LR6837), CE, China RoHS, EU RoHS, REACH SVHC
Applications
This receptacle is ideal for use in industrial environments where durable and secure connections are essential. Its robust construction and compliance with multiple standards make it suitable for a wide range of applications, including automation systems, machinery, and equipment requiring reliable power and signal transmission.
Additional Information
The Brad Connectivity 1R6006A20A120 features a single keyway design for easy alignment and mating, ensuring consistent and low-resistance connections. The die-cast zinc body with black epoxy coating provides enhanced durability and resistance to environmental factors. The 16 AWG PVC leads offer flexibility and ease of installation in various configurations.
For detailed specifications and installation guidelines, please refer to the manufacturer’s datasheet.
