Bailey Module Mounting Unit IEMMU11

Bailey Module Mounting Unit IEMMU11

The Bailey Module Mounting Unit IEMMU11 is a robust and versatile component designed to house and support up to 12 system modules within the ABB Infi 90 Distributed Control System (DCS). Its rear-mounted configuration ensures efficient space utilization and streamlined integration into standard 19-inch industrial cabinets.

Key Features

• Module Capacity: Accommodates up to 12 system modules, or 10 system modules alongside a maximum of two power modules, such as IEPAS02, IEPDS01/02, IEPAF02, and IEPDF01/02.
• Power Distribution: Efficiently distributes regulated DC voltages (+5V, +15V, –15V, and +24V) and primary power inputs of 120/240 VAC or 24/48 VDC to the installed modules.
• Signal Management: Facilitates the distribution of I/O expander bus, module bus, and Controlway signals, ensuring seamless communication between modules.
• Environmental Resilience: Operates reliably within a temperature range of 0°C to 70°C (32°F to 158°F) and a relative humidity of 5% to 95% up to 55°C (131°F), non-condensing.
• Standardized Mounting: Designed for easy installation in standard 483-mm (19-inch) cabinets, adhering to industry mounting standards.

Specifications

• Dimensions: 483 mm x 178 mm x 304 mm (19 in. x 7 in. x 12.2 in.)
• Weight: Approximately 3.63 kg (8.0 lbs)
• Operating Temperature: 0° to 70°C (32° to 158°F)
• Storage Temperature: –40° to 85°C (–40° to 185°F)
• Operating Humidity: 5% to 95% up to 55°C (131°F), non-condensing; 5% to 45% up to 70°C (158°F), non-condensing
• Storage Humidity: 0% to 95%, non-condensing
• Air Quality: Noncorrosive
• Primary Power: 120/240 VAC, 24/48 VDC
• Regulated DC Voltages: +5 VDC, +15 VDC, –15 VDC, +24 VDC, MCOM, I/OCOM

Certifications

• CSA Certification: Approved for use as process control equipment in ordinary (nonhazardous) locations.
• Nonincendive Ratings: CSA: Class I, Division 2, Groups A, B, C, D; FM: Class I, Division 2, Groups A, B, C, D
• CE Mark: Compliant with EMC Directive 89/336/EEC, including amendments 92/31/EEC and 93/68/EEC
• Flammability: Materials rated at V0, V1, V2, or V5; wires and cables rated UL VW-1
• Installation Category: IEC 1010-1 Category I for outputs, Category II for mains

The IEMMU11 Module Mounting Unit is an essential component for industrial control systems, offering reliable module housing, efficient power distribution, and robust environmental performance, making it suitable for a wide range of industrial applications.
