Marcon AWF-M41 820µF 400V Electrolytic Capacitor 85°C The Marcon AWF-M41 is a high-performance aluminum electrolytic capacitor designed to meet the demands of modern electronic applications. With a capacitance of 820 microfarads (µF) and a voltage rating of 400 volts (V), this capacitor is engineered to deliver reliable performance in circuits requiring substantial energy storage and voltage handling capabilities. Key Features Capacitance: 820µF Voltage Rating: 400V Temperature Range: -25°C to +85°C Capacitance Tolerance: ±20% at 25°C and 120Hz Dissipation Factor (tan?): Maximum of 0.15 at 25°C and 120Hz Leakage Current: I = CV or 3000µA, whichever is smaller, after 5 minutes of applying the rated voltage Endurance: Capable of operating for 3,000 hours at 85°C with the rated ripple current applied, maintaining capacitance change within ±20% of the initial value Shelf Life: Maintains performance after 1,000 hours at 85°C without voltage applied, with capacitance change within ±20% of the initial value Applications The Marcon AWF-M41 capacitor is suitable for a wide range of applications, including: Power supply filtering Energy storage in industrial equipment DC-DC converters Audio equipment General-purpose electronic circuits requiring high capacitance and voltage ratings Dimensions The capacitor features a compact design with the following approximate dimensions: Diameter: 35 mm Height: 58 mm These dimensions make it suitable for applications where space is a consideration, without compromising on performance. Compliance and Standards The Marcon AWF-M41 conforms to JIS-C-5101-4 (1998), characteristic W, ensuring adherence to industry standards for quality and reliability. In summary, the Marcon AWF-M41 820µF 400V Electrolytic Capacitor is a robust and reliable component, ideal for applications requiring high capacitance, voltage handling, and stability over a wide temperature range.
