Modicon AS-B805-016 Input Module The Modicon AS-B805-016 is a 16-point, 115 VAC input module designed to seamlessly integrate with industrial automation systems. As part of the 800 Series I/O, this module efficiently converts switched input signals into logic voltage levels, facilitating reliable communication with programmable logic controllers (PLCs). Key Features Input Capacity: Accommodates up to 16 inputs, organized into two groups of eight, allowing for structured signal management. Voltage Range: Operates within an 80 to 130 VAC range at 47 to 63 Hz, ensuring compatibility with standard industrial power supplies. Input Sources: Capable of receiving signals from various devices, including push buttons, limit switches, proximity sensors, and other 115 VAC sources. Electrical Isolation: Each input point is electrically isolated from the logic circuitry, enhancing system safety and reliability. Response Time: Features a typical OFF-to-ON response time of 4 ms and an ON-to-OFF response time of 11 ms, ensuring prompt signal processing. Wetting Current: Maintains a typical wetting current of 6 mA at 115 VAC, ensuring consistent signal detection. Design and Installation The AS-B805-016 module is engineered for user-friendly installation and maintenance: Standard Screw Terminal Strip: Facilitates straightforward user connections, simplifying the wiring process. Rigid Wiring System: Allows for module insertion or removal without disturbing existing wiring, minimizing downtime during maintenance. Technical Specifications Operating Voltage: 80 to 130 VAC at 47 to 63 Hz Maximum Input Voltage: Continuous 130 VAC; Surge 220 VAC for one cycle ON Conditions: 80 to 130 VAC (Z<1k?) OFF Conditions: 0 to 35 VAC (Z=0 ?); 0 to 130 VAC (Z>40 k?) Power Requirements: +5 V at 40 mA; +4.3 V at 1 mA; -5 V at 14 mA Space Required: 1 slot Weight: 2.2 lbs (1.01 kg) The Modicon AS-B805-016 Input Module stands as a reliable and efficient solution for industrial automation applications, offering robust performance and ease of integration into existing systems.
