Allen Bradley Contactor 9A 600VAC 509-TOD /B

The Allen Bradley 509-TOD /B is a robust and reliable NEMA Size 00 non-reversing starter, designed to handle demanding industrial applications.

Key Features

• Current and Voltage Ratings: Supports a continuous current of 9A and operates at up to 600VAC, making it suitable for various motor control tasks.
• Control Voltage: Equipped with a coil that operates at 110V AC (50 Hz) or 120V AC (60 Hz), ensuring compatibility with standard control circuits.
• Overload Protection: Features a eutectic alloy overload relay, providing effective protection against overcurrent conditions.
• Auxiliary Contacts: Includes one normally open auxiliary contact on the overload relay, facilitating integration with control systems.
• Construction: Built with corrosion-resistant metal parts and an open-type enclosure, ensuring durability and ease of maintenance.

Technical Specifications

• Service Limit Current Rating: 11A
• Heat Dissipation: 2.7 W
• Coil Operating Limits: 85% to 110% of rated voltage
• Operating Volt-Amperes Burden: Sealed: 8VA at 60 Hz
• Maximum Horsepower Rating: 2 HP at 575V load voltage, 3-phase (non-plugging and non-jogging duty)
• Mechanical Life Operations: 10 million operations
• Operating Temperature: Up to 65°C
• Altitude: Up to 10,000 ft before derating

The Allen Bradley 509-TOD /B starter is engineered for high performance and longevity, making it an excellent choice for industrial motor control applications.
