ABB SACE Tmax T3 N 225 Circuit Breaker 3 Pole N5596 E93565

ABB SACE Tmax T3 N 225 Circuit Breaker 3 Pole N5596 E93565

The ABB SACE Tmax T3 N 225 is a robust molded case circuit breaker designed to provide reliable protection for electrical systems. With a 225-ampere rating and three-pole configuration, it ensures efficient management of electrical circuits in various industrial and commercial applications.

Key Features

• High Breaking Capacity: The T3 N 225 offers substantial short-circuit breaking capacity, ensuring safety and reliability in diverse voltage levels.
• Thermal-Magnetic Trip Unit: Equipped with a fixed thermal and fixed magnetic trip unit, it provides consistent protection against overloads and short circuits.
• Compact Design: Its compact dimensions allow for flexible installation, making it suitable for space-constrained environments.
• Compliance and Certification: The circuit breaker meets UL 489 standards and carries the E93565 certification, ensuring adherence to industry safety and performance requirements.

Specifications

• Manufacturer: ABB
• Model: SACE Tmax T3 N 225
• Number of Poles: 3
• Rated Current: 225 A
• Voltage Rating: Up to 600 VAC
• Interrupting Capacity: 35 kA at 480 VAC
• Trip Unit Type: Fixed Thermal / Fixed Magnetic
• Mounting: Panel
• Certifications: UL 489, CSA

The ABB SACE Tmax T3 N 225 circuit breaker is engineered to deliver dependable performance, safeguarding electrical installations against potential faults and ensuring operational continuity.
