General Electric 8DW41VY33 Type DW-41 Analog DC Voltmeter The General Electric 8DW41VY33 Type DW-41 is a precision analog DC voltmeter designed for accurate voltage measurement in various electrical applications. This instrument combines reliability with a user-friendly interface, making it suitable for both industrial and laboratory environments. Key Features Measurement Range: Capable of measuring DC voltages from 0 to 40 volts, accommodating a wide array of testing scenarios. Accuracy: Delivers precise readings with an accuracy of ±2% at full scale, ensuring dependable measurements. Scale and Display: Features a clear scale with 40 divisions, each marked in black against a silver background for enhanced readability. Movement Type: Utilizes a moving coil with a permanent magnet, providing stable and consistent needle movement. Mounting Design: Engineered for panel installation with a three-hole bolt circle arrangement, facilitating secure and straightforward mounting. Durability: Constructed with a plastic case, offering resilience and longevity in various operating conditions. Technical Specifications Overall Diameter: 2.562 inches Mounting Hole Diameter: 0.116 inches Meter Depth Behind Mounting Flange: 1.594 inches Mounting Bolt Circle Diameter: 2.312 inches Meter Body Diameter Behind Mounting Flange: Between 2.047 and 2.057 inches Mounting Facility Type and Quantity: Three unthreaded holes Movement Suspension Method: Jewel pivot base Sensitivity Rating: 200 ohms per volt Circuit Attachment Method and Quantity: Two threaded studs Style Designator: C1 round flush mounting The General Electric 8DW41VY33 Type DW-41 Analog DC Voltmeter stands as a reliable and precise instrument for DC voltage measurement, embodying quality craftsmanship and thoughtful design to meet the demands of professionals in the field.
