Mitsumi MD11-UB3691 RF Modulator TV Tuner Module Coax Output

The Mitsumi MD11-UB3691 RF Modulator TV Tuner Module is a compact and efficient solution designed to convert audio and video signals into RF signals, enabling seamless integration with television systems that lack direct AV input capabilities.

Key Features

• Signal Conversion: Transforms composite video and audio inputs into RF signals, facilitating compatibility with older television models that only accept coaxial input.
• Channel Selection: Equipped with adjustable channel settings, allowing users to select the desired output channel for optimal reception.
• Compact Design: Its small form factor ensures easy integration into various electronic setups without occupying significant space.
• Versatile Connectivity: Features standard input and output connectors, including RCA for audio and video input and coaxial for RF output, ensuring broad compatibility with a range of devices.

Applications

The MD11-UB3691 is ideal for:

• Home Entertainment Systems: Connecting DVD players, gaming consoles, or other AV equipment to televisions lacking AV inputs.
• Surveillance Systems: Integrating security cameras with monitors or recording devices through RF connections.
• Educational Institutions: Facilitating the distribution of audio-visual content to multiple televisions via RF signals.

Technical Specifications

• Input: Composite video and audio signals via RCA connectors.
• Output: RF signal through coaxial connector.
• Channel Range: Selectable channels within the standard RF spectrum.
• Power Requirements: Operates on standard DC voltage, ensuring energy efficiency.

The Mitsumi MD11-UB3691 RF Modulator TV Tuner Module offers a reliable and straightforward solution for converting AV signals to RF, enhancing the versatility and connectivity of various audio-visual systems.
